    IP66 103Kwh Electric Vehicle Battery 15P108S For Truck

    Ask Lasest Price
    Brand Name : Soundon
    Model Number : SD-EV-394.2-262.5
    Certification : CE, MSDS, ROHS,UL
    Price : Negotiable
    Supply Ability : 50units / week
    Delivery Time : 30 working days after payment
    • Product Details
    • Company Profile

    IP66 103Kwh Electric Vehicle Battery 15P108S For Truck

    103kwh Electric Vehicle Battery With UL Certificated And High Energy Dendity For Heavy Truck,Logistic Truck,


    ContentParameter
    Voltage324V---453.6V(335.8V)
    Energy(KWh)23±2℃,1/3C103.4kWh
    Capacity(Ah)23±2℃,1/3C262.5Ah
    CellSEPNi8688190P-17.5Ah
    Configuration15P108S
    Recommended ambient temperature range(℃)Discharge-20~55℃,Charge 0~55℃
    Environmental Relative Humidity Recommended5%~95%
    Storage temperature

    -20~25℃(3-6months,50%SOC)

    -20~45℃(1-3months,50%SOC)

    -20~60℃(less than 1 month,50%SOC)

    Maximum Continuous Discharge Current≤262.5A
    Maximum Continuous Charging Current≤262.5A
    Insulation resistance factory test value(Ω)≥20MΩ
    Waterproof Grade of Battery BoxIP66
    Cooling modeNatural cooling


    Battery Model


    Cell Model8688190-17.5Ah
    Model Type5P1S
    Model Size (H*W*T)242× 97× 45.3(mm)

    Rated Capacity Module


    87.5Ah

    Nominal Voltage Module


    3.65V
    Module Weight≈1.51Kg
    The Module Of Energy Density211.5Wh/kg

    Battery Module picture



    Application


    electric truck ,delivery truck ,heavey duty fleets




    Battery cell parameters


    Capacity voltage: 3.6V17.5Ah 1C discharging (25±2 degree)


    Charging end of voltage :4.2V


    Standard charging and discharging current :0.5C


    max continuous charge and discharge current :1C


    max pluse charging current :1.5C(15-45 degree) < 30S


    max pluse discharging current :3C (15-45 degree) < 30S


    Working temperature : Charging:-10~45 degree


    Discharging :-20~55 degree


    Battery cell with UL certificate
