| Item | Model 1 | Model 2 |
PV
| Input voltage range | 60V DC ～ 90V DC |
| Max charge current | 10-40A | 10-60A |
| Max energy conversion efficiency | 98% |
| Recommended power | 1500W | 2500W |
Input AC
| Input voltage range | 165- 275V AC / 85-135V AC |
| Input frequency | 45-65 Hz |
| Short circuit protection | Fuse | Circuit Breaker |
| Output | Output voltage | 220V AC/110V AC±5％ 50Hz/60Hz±1％ |
| Output frequency | 1000W | 2000W |
| Max efficiency | 84.50% |
| Short circuit | Auto power-off |
| Other | Protection level | IP20 |
| Permissible temperature | 0℃ ～ 40℃ |
| Permissible relative humidity | 10％ ～ 90％ |
| Sound | ≤ 50dB |
Home energy storage battery system
LED display function
1 system condition 2 :total generater energy 3 daily generated
energy 4 AC input 5 :battery condition 6 Loading output
7 PV input 8 Main controll display 9 models selection 10 power
gernerate record 11 system setting
12 Language selection
Solar Power Automatic Charging Function
When at night or the machine is not used for supplying the
electricity, we strongly require the
users to shut down the machine (Make sure the air switch of the
battery is closed) to avoid the
consumption of the battery power. In the next day when solar power
is supplied, the machine
will automatically use it for charging (even the machine is not
powered on)
Batteries setting and maintaining .
Batteries need maintain when be used at first time. Set “rated
capacity”, “current capacity”,
battery SOH”. If SOC not exactly display, we need adjust SOC. As
follow:
a. Turn off PV and AC input. Turn on inverter and connect a load,
untill battery under
voltage protect and inverter turnoff.
b. Turn on PV and AC input, PV will charging battery. When SOC
change to 100%.
Adjust step end.
If the product will not be used for over 7 days, please press the
power-off button to close the
inverter. Please close the back panel, the AC input switch, the PV
switch and the battery pack
switch successively. If the product will not be used for over 3
months, please open the
battery pack swith and the PV switch to let PV charge the battery
pack for over 12 hours for
extending the life of the pack
Description:
Relying on our high quality lithium battery technology, we Soundon
New Energy can provide home energy storage, distributed energy
system, micro-grid, which forms a complete set and series of energy
storage system solutions.
Peak shaving
Emergency power supply during electrical outages
Make compensation for PV generating, and smoothen the power output
Act according to requirement of urban grid alteration, ensure
safety of the grid
Use for urgency transient active power response and voltage
supporting
Reduce the electricity cost
Allow you to monitor your electrical consumption
Our Competitive Advantages:
- We provide customization for free
- Global after-sales service.
- Patented technology
- ISO9001, ISO14001, ISO/TS16949, RoHS, CB and other certifications
obtained
- Samples can be sent before the bulk order.
